Shimano Tiagra Game Reel Series
Description
Retrieve per crank: 104/46 cm
Bearings: 4
Max Drag: 15 kg
Mono Cap: 23 kg / 521 m
Drag Type: LD
Weight: 1576 g
Gear Ratio: 3.9:1, 1.7:1
In a fight with a very large fish, the drag force cannot be prevented from decreasing due to the frictional heat of the drag.
TIAGRA is equipped with a thermo-sensitive hydraulic compensating drag mechanism* that compensates for reduced drag force by utilizing frictional heat in reverse.
In addition to high drag performance, the high and low two-speed gear system enables anglers to fight with very large fish to their advantage.
HAGANE is a Shimano reel design concept created to withstand continual use and extreme abuse. HAGANE is an innovation with built-in toughness and durability that works alongside Shimano's precision engineering. HAGANE is for all anglers.
The HAGANE Body is a metal reel body with high rigidity. The body rigidity and impact resistance virtually eliminate body flexing on the reel while fighting a fish. The result transforms the angler's actions directly into cranking power,
A-RB stainless-steel ball bearings are specially treated to drastically increase the corrosion resistance of the bearing.
Retrieve per crank: 94/38 cm
Bearings: 4
Max Drag: 20 kg
Mono Cap: 36 kg / 503 m
Drag Type: LD
Weight: 2447 g
Gear Ratio: 3.1:1, 1.3:1
Retrieve per crank: 94/38 cm
Bearings: 4
Max Drag: 20 kg
Mono Cap: 23 kg / 548 m
Drag Type: LD
Weight: 2447 g
Gear Ratio: 3.1:1, 1.3:1
Retrieve per crank: 94/48 cm
Bearings: 4
Max Drag: 24 kg
Mono Cap: 36 kg / 868 m
Drag Type: LD
Weight: 3266 g
Gear Ratio: 2.5:1, 1.3:1
Shimano Tiagra A Featured Highlights
A-RB (Anti-Rust Bearings)
Our specially treated stainless steel ball bearings are at least 10 times more corrosion resistant than standard stainless steel ball bearings.
Forged Aluminum Spool
These spools are made from cold forged aluminum then machined to provide an extremely dense, solid construction that can withstand the heavy drag pressures the reels can apply.
Chrome Plated Sideplate Screws
The sideplate screws are chrome plated to prevent corrosion.
2-Speed Gearing
Uses 2 sets of gears that are always engaged for quick, easy gear ratio changes even under load.
Ratcheting Drag Lever
eliminates the chance of the drag lever backing off due to boat vibration and allows for more precise adjustment.
Twin Disk Drag System
uses two drag disks and a floating drag plate to effectively double the drag surface which provides a wide range of settings and increased durability (TI16 & TI130A only).
Clicker
The clicker increases the tension on freespool and activates a clicking alarm when a fish bites.
Septon
The handle grip material, Septon, is soft to the touch and does not get slippery when wet (not available on TI12 & TI16).
Permalube
This lubrication improves freespool while maintaining protection and durability of moving parts.
Metal Series
With the Metal Series, metal frames keep moving parts in precise alignment for increased efficiency and durability.
Machined Aluminum Frame
These frames are machined from solid aluminum pipestock, which makes them incredibly rigid and strong for ultra tight tolerances.
Offset Ergonomic Power Grip
The power grip is offset on multiple axes to allow natural hand, arm and wrist angles to improve comfort and power (not available on (TI12 & TI16).
Ergonomic Power Handle
Comfortable, non-slip grip provides maximum comfort and torque (TI12 & TI16).
| Image | Code | Description | Product Name | Price | Quantity |
|---|---|---|---|---|---|
|
|
TRTI30W
|
DescriptionRetrieve per crank: 104/46 cm |
Shimano Tiagra Ti-30Wlrsa Trolling Reel
|
$899.00 (Incl GST)
|
|
|
TRTI50L
|
DescriptionIn a fight with a very large fish, the drag force cannot be prevented from decreasing due to the frictional heat of the drag. |
Shimano Tiagra Ti-50Wlrsa Trolling Reel
|
$1,099.00 (Incl GST)
|
|
|
TRTI50S
|
DescriptionRetrieve per crank: 94/38 cm |
Shimano Tiagra Ti-50A Trolling Reel
|
$899.00 (Incl GST)
|
|
|
TRTI80W
|
DescriptionRetrieve per crank: 94/48 cm |
Shimano Tiagra Ti-80W Trolling Reel
|
$1,299.00 (Incl GST)
|
|
|
TRTI130
|
DescriptionShimano Tiagra A Featured Highlights |
Shimano Tiagra Ti-130W Lrsa Trolling Reel
|
$1,799.00 (Incl GST)
|
